This article is a continuation of "Where's the Metadata?", focusing on obtaining Metadata from a Relational Database Management Systems (RDMS). I will cover:

• Extracting Table Information
• Extracting Column Information
• Data Profiling



I've included sample scripts for collecting basic Metadata from a MS SQL Server database. (Other RDMS, like PostgreSQL or MySQL, will be similar for the INFORMATION_SCHEMA tables, but the use of MS_Description field or sys tables will be specific to MS SQL Server).

Table Information

This script will get you all the details about eachTable, including where it is a View, the MS_Description, a count of all Rows in the table, and the number of Columns in the table.
Pro Tip: If you plan to log the Row count on a regular basis to monitor growth of a certain dataset, you will want to capture the date of this script was ran.

/**  Retrieve information for all Tables in Schema **/
DECLARE @SchemaName VARCHAR(50) = 'dbo';
SELECT
    t.TABLE_CATALOG as [Database],
    t.TABLE_SCHEMA as [Schema],
    t.TABLE_NAME as [Table],
    CAST(CASE
        WHEN TABLE_TYPE = 'VIEW' then 1
        ELSE 0
    END AS BIT) as [IsView],
    ex.value [Description],
    p.rows [RowCount],
    count(c.COLUMN_NAME) [Columns],
    GETUTCDATE() [DateCapturedUtc]
FROM
    INFORMATION_SCHEMA.TABLES as t
LEFT JOIN
    sys.extended_properties as ex
        ON ex.major_id = OBJECT_ID(t.TABLE_SCHEMA+'.'+t.TABLE_NAME) AND minor_id = 0 AND ex.name = 'MS_Description'
LEFT JOIN
    sys.partitions as p on p.object_id= OBJECT_ID(t.TABLE_SCHEMA+'.'+t.TABLE_NAME) and p.index_id = 1
LEFT JOIN
    INFORMATION_SCHEMA.COLUMNS as c on t.TABLE_NAME = c.TABLE_NAME and t.TABLE_SCHEMA = t.TABLE_SCHEMA and t.TABLE_CATALOG = c.TABLE_CATALOG
WHERE
    t.TABLE_SCHEMA = @SchemaName
GROUP BY
    t.TABLE_CATALOG,
    t.TABLE_SCHEMA,
    t.TABLE_NAME,
    t.TABLE_TYPE,
    ex.value,
    p.rows
ORDER BY
    [Database], [Schema], [Table]
 GO

Table Column information

This script will get you all the details about each Column in a Table, including the Data Type, Precision, Default Value, whether it allows NULLS, and the MS_Description

DECLARE @SchemaName VARCHAR(50) = 'dbo';
DECLARE @TableName VARCHAR(50) = 'table_name';
SELECT
    c.TABLE_SCHEMA as [Schema],
    c.TABLE_NAME as [Table],
    c.COLUMN_NAME as [Column],
    CASE
        WHEN c.DATA_TYPE in ('int','datetime','date','time','money','bit','float','uniqueidentifier') THEN UPPER(c.DATA_TYPE)
        WHEN c.DATA_TYPE in ('numeric','decimal') THEN CONCAT(UPPER(c.DATA_TYPE), '(',c.NUMERIC_PRECISION,',',c.NUMERIC_SCALE,')')
        WHEN c.DATA_TYPE in ('datetime2') THEN CONCAT(UPPER(c.DATA_TYPE), '(',c.DATETIME_PRECISION,')')
        ELSE CONCAT(UPPER(c.DATA_TYPE), '(',iif(c.CHARACTER_MAXIMUM_LENGTH = -1,'max',CAST(CHARACTER_MAXIMUM_LENGTH AS VARCHAR)),')')
    END [ColumnType],
    REPLACE(REPLACE(
        c.COLUMN_DEFAULT
        ,'(',''),')','')
    [DefaultValue],
    c.IS_NULLABLE [AllowNulls],
    p.value [Description]
FROM
    INFORMATION_SCHEMA.COLUMNS as c
LEFT JOIN
    sys.extended_properties as p
        ON   p.major_id = OBJECT_ID(c.TABLE_SCHEMA+'.'+c.TABLE_NAME)   AND p.minor_id = c.ORDINAL_POSITION   AND p.name = 'MS_Description'
WHERE
      OBJECTPROPERTY(OBJECT_ID(c.TABLE_SCHEMA+'.'+c.TABLE_NAME), 'IsMsShipped')=0
     AND
     c.TABLE_NAME = @TableName
     AND c.TABLE_SCHEMA = @SchemaName
ORDER BY
    [Schema], [Table], c.ORDINAL_POSITION

Data Profiling

Data Profiling will give you a glimpse into how well your SQL schema fits the data (to determine if any optimization is needed), and what is the quality of your data. For example, you might want to know the min/max value, the average value, the number of NULLs (completeness), number of distinct values, etc.

The query below is based on Data Profiling with T-SQL (SQL Server Central). In addition to your data profile, it also provides actionable recommendations! For example:

• Seems empty - is it required?
• There is a large percentage of NULLs - attention may be required
• Few distinct elements - potential for reference/lookup table (contains NULLs)
• Few distinct elements - potential for Foreign Key.
• Possibly could be SMALLINT type.
• Could benefit from sparse columns.
• Possibly could be DATE type
• Possibly could be one of the NUMERIC types.

-----------------------------------------------------------------------
-- User-defined variables
-----------------------------------------------------------------------
USE Products                                        -- Your database here
GO

DECLARE @TABLE_SCHEMA NVARCHAR(128) = 'dbo'         -- Your schema here
DECLARE @TABLE_NAME NVARCHAR(128) = 'table_name'        -- Your table here

DECLARE @ColumnListIN NVARCHAR(4000) = ''           -- Enter a comma-separated list of specific columns to profile, or leave blank for all
DECLARE @TextCol BIT = 1                            -- Analyse all text (char/varchar/nvarchar) data type columns
DECLARE @NumCol BIT = 1                             -- Analyse all numeric data type columns
DECLARE @DateCol BIT = 1                            -- Analyse all date data type data type columns
DECLARE @LobCol BIT = 1                             -- Analyse all VAR(char/nchar/binary) MAX data type columns (potentially time-consuming)
DECLARE @AdvancedAnalysis BIT = 0                   -- Perform advanced analysis (threshold counts/domain analysis) (potentially time-consuming)
DECLARE @DistinctValuesMinimum INT = 200            -- Minimum number of distinct values to suggest a reference table and/or perform domain analysis
DECLARE @BoundaryPercent NUMERIC(3,2) = 0.57        -- Percent of records at upper/lower threshold to suggest a possible anomaly
DECLARE @NullBoundaryPercent NUMERIC(5,2) = 90.00   -- Percent of NULLs to suggest a possible anomaly
DECLARE @DataTypePercentage INT = 2                 -- Percentage variance allowed when suggesting another data type for a column

-----------------------------------------------------------------------
-- Process variables
-----------------------------------------------------------------------
DECLARE @DATA_TYPE VARCHAR(128) = ''
DECLARE @FULLSQL VARCHAR(MAX) = ''
DECLARE @SQLMETADATA VARCHAR(MAX) = ''
DECLARE @NUMSQL VARCHAR(MAX) = ''
DECLARE @DATESQL VARCHAR(MAX) = ''
DECLARE @LOBSQL VARCHAR(MAX) = ''
DECLARE @COLUMN_NAME VARCHAR(128)
DECLARE @CHARACTER_MAXIMUM_LENGTH INT
DECLARE @ROWCOUNT BIGINT = 0
DECLARE @ColumnList VARCHAR(4000) = '  '
DECLARE @TableCheck TINYINT
DECLARE @ColumnCheck SMALLINT
DECLARE @DataTypeVariance INT
-----------------------------------------------------------------------
-- Start the process:
BEGIN TRY
-- Test that the schema and table exist
    SELECT @TableCheck = COUNT (*) FROM INFORMATION_SCHEMA.TABLES WHERE TABLE_SCHEMA = @TABLE_SCHEMA AND TABLE_NAME = @TABLE_NAME

    IF @TableCheck <> 1
    BEGIN
    RAISERROR ('The table does not exist',16,1)
    RETURN
    END
    -----------------------------------------------------------------------
    -- Parse list of columns to process / get list of columns according to types required
    -----------------------------------------------------------------------
    IF OBJECT_ID('tempdb..#ColumnList') IS NOT NULL
    DROP TABLE tempdb..#ColumnList;
    CREATE TABLE #ColumnList (COLUMN_NAME VARCHAR(128), DATA_TYPE VARCHAR(128), CHARACTER_MAXIMUM_LENGTH INT) -- Used to hold list of columns to process
    IF @ColumnListIN <> ''              -- See if there is a list of columns to process
    BEGIN
    -- Process list
    SET @ColumnList = @ColumnListIN + ','
    DECLARE @CharPosition int
    WHILE CHARINDEX(',', @ColumnList) > 0
        BEGIN
          SET @CharPosition = CHARINDEX(',', @ColumnList)
          INSERT INTO #ColumnList (COLUMN_NAME)  VALUES (LTRIM(RTRIM(LEFT(@ColumnList, @CharPosition - 1))))
          SET @ColumnList = STUFF(@ColumnList, 1, @CharPosition, '')
        END  -- While loop
    -- update with datatype and length
        UPDATE      CL
        SET         CL.CHARACTER_MAXIMUM_LENGTH = ISNULL(ISC.CHARACTER_MAXIMUM_LENGTH,0)
                    ,CL.DATA_TYPE = ISC.DATA_TYPE
        FROM        #ColumnList CL
                    INNER JOIN INFORMATION_SCHEMA.COLUMNS ISC
                    ON  CL.COLUMN_NAME = ISC.COLUMN_NAME
        WHERE       ISC.TABLE_NAME = @TABLE_NAME
                    AND ISC.TABLE_SCHEMA = @TABLE_SCHEMA
    END -- If test for list of column names
ELSE
    BEGIN  -- Use all column names, to avoid filtering
        IF @TextCol = 1
            BEGIN
            INSERT INTO     #ColumnList (COLUMN_NAME, DATA_TYPE, CHARACTER_MAXIMUM_LENGTH)
            SELECT          COLUMN_NAME, DATA_TYPE, CHARACTER_MAXIMUM_LENGTH FROM INFORMATION_SCHEMA.COLUMNS
            WHERE           DATA_TYPE IN ('varchar', 'nvarchar', 'char', 'nchar', 'binary')
                            AND TABLE_NAME = @TABLE_NAME
                            AND TABLE_SCHEMA = @TABLE_SCHEMA
                            AND CHARACTER_MAXIMUM_LENGTH > 0
            END
        IF @NumCol = 1
            BEGIN
            INSERT INTO     #ColumnList (COLUMN_NAME, DATA_TYPE, CHARACTER_MAXIMUM_LENGTH)
            SELECT          COLUMN_NAME, DATA_TYPE, ISNULL(CHARACTER_MAXIMUM_LENGTH,0) FROM INFORMATION_SCHEMA.COLUMNS
            WHERE           DATA_TYPE IN ('numeric', 'int', 'bigint', 'tinyint', 'smallint', 'decimal', 'money', 'smallmoney', 'float','real')
                            AND TABLE_NAME = @TABLE_NAME
                            AND TABLE_SCHEMA = @TABLE_SCHEMA
            END
        IF @DateCol = 1
            BEGIN
            INSERT INTO     #ColumnList (COLUMN_NAME, DATA_TYPE, CHARACTER_MAXIMUM_LENGTH)
            SELECT          COLUMN_NAME, DATA_TYPE, ISNULL(CHARACTER_MAXIMUM_LENGTH,0) FROM INFORMATION_SCHEMA.COLUMNS
            WHERE           DATA_TYPE IN ('Date', 'DateTime', 'SmallDateTime', 'DateTime2', 'time')
                            AND TABLE_NAME = @TABLE_NAME
                            AND TABLE_SCHEMA = @TABLE_SCHEMA
            END
        IF @LOBCol = 1
            BEGIN
            INSERT INTO     #ColumnList (COLUMN_NAME, DATA_TYPE, CHARACTER_MAXIMUM_LENGTH)
            SELECT          COLUMN_NAME, DATA_TYPE, CHARACTER_MAXIMUM_LENGTH FROM INFORMATION_SCHEMA.COLUMNS
            WHERE           DATA_TYPE IN ('varchar', 'nvarchar', 'varbinary', 'xml')
                            AND TABLE_NAME = @TABLE_NAME
                            AND TABLE_SCHEMA = @TABLE_SCHEMA
                            AND CHARACTER_MAXIMUM_LENGTH = -1
            END
    END -- Else test to get all column names

    -----------------------------------------------------------------------

    -- Test that there are columns to analyse
    SELECT @ColumnCheck = COUNT (*) FROM #ColumnList WHERE DATA_TYPE IS NOT NULL
    IF @ColumnCheck = 0
    BEGIN
    RAISERROR ('The columns do not exist in the selected database or no columns are selected',16,1)
    RETURN
    END

    -----------------------------------------------------------------------
    -- Create Temp table used to hold profiling data
    -----------------------------------------------------------------------
    IF OBJECT_ID('tempdb..#ProfileData') IS NOT NULL
    DROP TABLE tempdb..#ProfileData;

    CREATE TABLE #ProfileData
    (
    TABLE_SCHEMA NVARCHAR(128)
    ,TABLE_NAME NVARCHAR(128)
    ,COLUMN_NAME NVARCHAR(128)
    ,ColumnDataLength INT
    ,DataType VARCHAR(128)
    ,MinDataLength BIGINT
    ,MaxDataLength BIGINT
    ,AvgDataLength BIGINT
    ,MinDate SQL_VARIANT
    ,MaxDate  SQL_VARIANT
    ,NoDistinct BIGINT
    ,NoNulls NUMERIC(32,4)
    ,NoZeroLength NUMERIC(32,4)
    ,PercentageNulls NUMERIC(9,4)
    ,PercentageZeroLength NUMERIC(9,4)
    ,NoDateWithHourminuteSecond BIGINT NULL
    ,NoDateWithSecond BIGINT NULL
    ,NoIsNumeric BIGINT NULL
    ,NoIsDate BIGINT NULL
    ,NoAtLimit BIGINT NULL
    ,IsFK BIT NULL DEFAULT 0
    ,DataTypeComments NVARCHAR(1500)
    );

    -- Get row count

    DECLARE @ROWCOUNTTEXT NVARCHAR(1000) = ''
    DECLARE @ROWCOUNTPARAM NVARCHAR(50) = ''

    SET @ROWCOUNTTEXT = 'SELECT @ROWCOUNTOUT = COUNT (*) FROM ' + QUOTENAME(@TABLE_SCHEMA)  + '.' + QUOTENAME(@TABLE_NAME) + ' WITH (NOLOCK)'
    SET @ROWCOUNTPARAM = '@ROWCOUNTOUT INT OUTPUT'

    EXECUTE sp_executesql @ROWCOUNTTEXT, @ROWCOUNTPARAM, @ROWCOUNTOUT = @ROWCOUNT OUTPUT

    -----------------------------------------------------------------------

    -- Test that there are records to analyse
    IF @ROWCOUNT = 0
    BEGIN
    RAISERROR ('There is no data in the table to analyse',16,1)
    RETURN
    END

    -----------------------------------------------------------------------
    -- Define the dynamic SQL used for each column to analyse
    -----------------------------------------------------------------------
        SET @SQLMETADATA = 'INSERT INTO #ProfileData (ColumnDataLength,COLUMN_NAME,TABLE_SCHEMA,TABLE_NAME,DataType,MaxDataLength,MinDataLength,AvgDataLength,MaxDate,MinDate,NoDateWithHourminuteSecond,NoDateWithSecond,NoIsNumeric,NoIsDate,NoNulls,NoZeroLength,NoDistinct)'

        DECLARE SQLMETADATA_CUR CURSOR LOCAL FAST_FORWARD FOR

        SELECT COLUMN_NAME, CHARACTER_MAXIMUM_LENGTH, DATA_TYPE FROM #ColumnList

        OPEN SQLMETADATA_CUR
        FETCH NEXT FROM SQLMETADATA_CUR INTO @COLUMN_NAME, @CHARACTER_MAXIMUM_LENGTH, @DATA_TYPE

        WHILE @@FETCH_STATUS = 0
        BEGIN

        SET @SQLMETADATA = @SQLMETADATA +'
        SELECT TOP 100 PERCENT
        ' + CAST(@CHARACTER_MAXIMUM_LENGTH AS VARCHAR(20)) + '
        ,''' + QUOTENAME(@COLUMN_NAME) + '''
        ,''' + QUOTENAME(@TABLE_SCHEMA) + '''
        ,''' + QUOTENAME(@TABLE_NAME) + '''
        ,''' + @DATA_TYPE + ''''
        + CASE
        WHEN @DATA_TYPE IN ('varchar', 'nvarchar', 'char', 'nchar') AND @CHARACTER_MAXIMUM_LENGTH >= 0 THEN + '
        ,MAX(LEN(' + QUOTENAME(@COLUMN_NAME) + '))
        ,MIN(LEN(' + QUOTENAME(@COLUMN_NAME) + '))
        ,AVG(LEN(' + QUOTENAME(@COLUMN_NAME) + '))
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,(SELECT COUNT (*) from ' + QUOTENAME(@TABLE_SCHEMA) + '.' + QUOTENAME(@TABLE_NAME) + ' WHERE ISNUMERIC(' + QUOTENAME(@COLUMN_NAME) + ') = 1)
        ,(SELECT COUNT (*) from ' + QUOTENAME(@TABLE_SCHEMA) + '.' + QUOTENAME(@TABLE_NAME) + ' WHERE ISDATE(' + QUOTENAME(@COLUMN_NAME) + ') = 1) '
        WHEN @DATA_TYPE IN ('numeric', 'int', 'bigint', 'tinyint', 'smallint', 'decimal', 'money', 'smallmoney', 'float','real') THEN + '
        ,MAX(' + QUOTENAME(@COLUMN_NAME) + ')
        ,MIN(' + QUOTENAME(@COLUMN_NAME) + ')
        ,AVG(CAST(' + QUOTENAME(@COLUMN_NAME) + ' AS NUMERIC(36,2)))
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL '
        WHEN @DATA_TYPE IN ('DateTime', 'SmallDateTime') THEN + '
        ,NULL
        ,NULL
        ,NULL
        ,MAX(' + QUOTENAME(@COLUMN_NAME) + ')
        ,MIN(' + QUOTENAME(@COLUMN_NAME) + ')
        ,(SELECT COUNT (*) from ' + QUOTENAME(@TABLE_SCHEMA) + '.' + QUOTENAME(@TABLE_NAME) + ' WHERE (CONVERT(NUMERIC(20,12), ' + QUOTENAME(@COLUMN_NAME) + ' ) - FLOOR(CONVERT(NUMERIC(20,12), ' + QUOTENAME(@COLUMN_NAME) + ')) <> 0))
        ,(SELECT COUNT (*) from ' + QUOTENAME(@TABLE_SCHEMA) + '.' + QUOTENAME(@TABLE_NAME) + ' WHERE DATEPART(ss,' + QUOTENAME(@COLUMN_NAME) + ') <> 0 OR DATEPART(mcs,' + QUOTENAME(@COLUMN_NAME) + ') <> 0)
        ,NULL
        ,NULL '
        WHEN @DATA_TYPE IN ('DateTime2') THEN + '
        ,NULL
        ,NULL
        ,NULL
        ,MAX(' + QUOTENAME(@COLUMN_NAME) + ')
        ,MIN(' + QUOTENAME(@COLUMN_NAME) + ')
        ,NULL
        ,NULL
        ,NULL
        ,NULL '
        WHEN @DATA_TYPE IN ('Date') THEN + '
        ,NULL
        ,NULL
        ,NULL
        ,MAX(' + QUOTENAME(@COLUMN_NAME) + ')
        ,MIN(' + QUOTENAME(@COLUMN_NAME) + ')
        ,NULL
        ,NULL
        ,NULL
        ,NULL '
        WHEN @DATA_TYPE IN ('xml') THEN + '
        ,MAX(LEN(CAST(' + QUOTENAME(@COLUMN_NAME) + ' AS NVARCHAR(MAX))))
        ,MIN(LEN(CAST(' + QUOTENAME(@COLUMN_NAME) + ' AS NVARCHAR(MAX))))
        ,AVG(LEN(CAST(' + QUOTENAME(@COLUMN_NAME) + ' AS NVARCHAR(MAX))))
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL '
        WHEN @DATA_TYPE IN ('varbinary','varchar','nvarchar') AND @CHARACTER_MAXIMUM_LENGTH = -1 THEN + '
        ,MAX(LEN(' + QUOTENAME(@COLUMN_NAME) + '))
        ,MIN(LEN(' + QUOTENAME(@COLUMN_NAME) + '))
        ,AVG(LEN(' + QUOTENAME(@COLUMN_NAME) + '))
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL '
        WHEN @DATA_TYPE IN ('binary') THEN + '
        ,MAX(LEN(' + QUOTENAME(@COLUMN_NAME) + '))
        ,MIN(LEN(' + QUOTENAME(@COLUMN_NAME) + '))
        ,AVG(LEN(' + QUOTENAME(@COLUMN_NAME) + '))
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL '
        WHEN @DATA_TYPE IN ('time') THEN + '
        ,NULL
        ,NULL
        ,NULL
        ,MAX(' + QUOTENAME(@COLUMN_NAME) + ')
        ,MIN(' + QUOTENAME(@COLUMN_NAME) + ')
        ,NULL
        ,NULL
        ,NULL
        ,NULL '
        ELSE + '
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL
        ,NULL '
        END + '
        ,(SELECT COUNT(*) FROM ' + QUOTENAME(@TABLE_SCHEMA) + '.' + QUOTENAME(@TABLE_NAME) + ' WHERE ' + QUOTENAME(@COLUMN_NAME) + ' IS NULL)'
        + CASE
        WHEN @DATA_TYPE IN ('varchar', 'nvarchar', 'char', 'nchar') THEN + '
        ,(SELECT COUNT(*) FROM ' + QUOTENAME(@TABLE_SCHEMA) + '.' + QUOTENAME(@TABLE_NAME) + ' WHERE LEN(LTRIM(RTRIM(' + QUOTENAME(@COLUMN_NAME) + '))) = '''')'
        ELSE + '
        ,NULL'
        END + '
        ,(SELECT COUNT(DISTINCT ' + QUOTENAME(@COLUMN_NAME) + ') FROM ' + QUOTENAME(@TABLE_SCHEMA) + '.' + QUOTENAME(@TABLE_NAME) + ' WHERE ' + QUOTENAME(@COLUMN_NAME) + ' IS NOT NULL )
        FROM ' + QUOTENAME(@TABLE_SCHEMA) + '.' + QUOTENAME(@TABLE_NAME) + ' WITH (NOLOCK)

        UNION'

        FETCH NEXT FROM SQLMETADATA_CUR INTO @COLUMN_NAME, @CHARACTER_MAXIMUM_LENGTH, @DATA_TYPE
        END

        CLOSE SQLMETADATA_CUR
        DEALLOCATE SQLMETADATA_CUR
        SET @SQLMETADATA = LEFT(@SQLMETADATA, LEN(@SQLMETADATA) -5)

        EXEC  (@SQLMETADATA)

    -----------------------------------------------------------------------
    -- Final Calculations
    -----------------------------------------------------------------------

    -- Indicate Foreign Keys
    ;WITH FK_CTE (FKColumnName)
    AS
    (
    SELECT DISTINCT CU.COLUMN_NAME
    FROM            INFORMATION_SCHEMA.TABLE_CONSTRAINTS TC
                    INNER JOIN INFORMATION_SCHEMA.CONSTRAINT_COLUMN_USAGE CU
                    ON TC.CONSTRAINT_NAME = CU.CONSTRAINT_NAME
                    AND TC.TABLE_SCHEMA = CU.TABLE_SCHEMA
                    AND TC.TABLE_NAME = CU.TABLE_NAME
                    AND TC.TABLE_SCHEMA = @TABLE_SCHEMA
                    AND TC.TABLE_NAME = @TABLE_NAME
                    AND CONSTRAINT_TYPE = 'FOREIGN KEY'
    )

    UPDATE  P
    SET     P.IsFK = 1
    FROM    #ProfileData P
            INNER JOIN FK_CTE CTE
            ON P.COLUMN_NAME = CTE.FKColumnName

    -- Calculate percentages
    UPDATE      #ProfileData
    SET         PercentageNulls = (NoNulls / @ROWCOUNT) * 100
                ,PercentageZeroLength = (NoZeroLength / @ROWCOUNT) * 100
    -- Add any comments

    -- Datatype suggestions

    -- First get number of records where a variation could be an anomaly
    SET @DataTypeVariance = ROUND((@ROWCOUNT * @DataTypePercentage) / 100, 0)

    UPDATE      #ProfileData
    SET         DataTypeComments = 'Possibly could be one of the DATE types. '
    WHERE       NoIsDate BETWEEN (@ROWCOUNT -@DataTypeVariance) AND (@ROWCOUNT + @DataTypeVariance)
                AND DataType IN ('varchar', 'nvarchar', 'char', 'nchar')
    UPDATE      #ProfileData
    SET         DataTypeComments = 'Possibly could be one of the NUMERIC types. '
    WHERE       NoIsNumeric BETWEEN (@ROWCOUNT -@DataTypeVariance) AND (@ROWCOUNT + @DataTypeVariance)
                AND DataType IN ('varchar', 'nvarchar', 'char', 'nchar')
    UPDATE      #ProfileData
    SET         DataTypeComments = 'Possibly could be INT type. '
    WHERE       MinDataLength >= -2147483648
                AND MaxDataLength <= 2147483648
                AND DataType IN ('bigint')
    UPDATE      #ProfileData
    SET         DataTypeComments = 'Possibly could be SMALLINT type. '
    WHERE       MinDataLength >= -32768
                AND MaxDataLength <= 32767
                AND DataType IN ('bigint','int')
    UPDATE      #ProfileData
    SET         DataTypeComments = 'Possibly could be TINYINT type. '
    WHERE       MinDataLength >= 0
                AND MaxDataLength <= 255
                AND DataType IN ('bigint','int','smallint')
    UPDATE      #ProfileData
    SET         DataTypeComments = 'Possibly could be SMALLDATE type. '
    WHERE       NoDateWithSecond = 0
                AND MinDate >= '19000101'
                AND MaxDate <= '20790606'
                AND DataType IN ('datetime','datetime2')
    UPDATE      #ProfileData
    SET         DataTypeComments = 'Possibly could be DATE type (SQL Server 2008 only). '
    WHERE       NoDateWithHourminuteSecond = 0
                AND DataType IN ('datetime','datetime2')
    UPDATE      #ProfileData
    SET         DataTypeComments = 'Possibly could be DATETIME type. '
    WHERE       MinDate >= '17530101'
                AND MaxDate <= '99991231'
                AND DataType IN ('datetime2')

    -- Empty column suggestions
    UPDATE      #ProfileData
    SET         DataTypeComments = ISNULL(DataTypeComments,'') + 'Seems empty - is it required? '
    WHERE       (PercentageNulls = 100 OR PercentageZeroLength = 100)
                AND IsFK = 0

    -- Null column suggestions
    UPDATE      #ProfileData
    SET         DataTypeComments = ISNULL(DataTypeComments,'') + 'There is a large percentage of NULLs - attention may be required. '
    WHERE       PercentageNulls >= @NullBoundaryPercent

    -- Distinct value suggestions
    UPDATE      #ProfileData
    SET         DataTypeComments = ISNULL(DataTypeComments,'') + 'Few distinct elements - potential for reference/lookup table (contains NULLs).'
    WHERE       NoDistinct < @DistinctValuesMinimum
                AND @ROWCOUNT > @DistinctValuesMinimum
                AND IsFK = 0
                AND PercentageNulls <> 100
                AND NoNulls <> 0

    -- FK suggestions
    UPDATE      #ProfileData
    SET         DataTypeComments = ISNULL(DataTypeComments,'') + 'Few distinct elements - potential for Foreign Key.'
    WHERE       NoDistinct < @DistinctValuesMinimum
                AND @ROWCOUNT > @DistinctValuesMinimum
                AND IsFK = 0
                AND NoNulls = 0
                AND DataType NOT LIKE '%Date%'
                AND DataType <> 'Time'

    -- Filestream suggestions
    UPDATE      #ProfileData
    SET         DataTypeComments = 'Possibly a good candidate for FILESTREAM (SQL Server 2008 only).'
    WHERE       AvgDataLength >= 1000000
                AND DataType IN ('varbinary')
                AND ColumnDataLength = -1
    UPDATE      #ProfileData
    SET         DataTypeComments = 'Possibly not a good candidate for FILESTREAM (SQL Server 2008 only).'
    WHERE       AvgDataLength < 1000000
                AND DataType IN ('varbinary')
                AND ColumnDataLength = -1

    -- Sparse Column Suggestions
    IF OBJECT_ID('tempdb..#SparseThresholds') IS NOT NULL
    DROP TABLE tempdb..#SparseThresholds;

    CREATE TABLE #SparseThresholds (DataType VARCHAR(128), Threshold NUMERIC(9,4))
    INSERT INTO #SparseThresholds (DataType, Threshold)
    VALUES  ('tinyint',86),
            ('smallint',76),
            ('int',64),
            ('bigint',52),
            ('real',64),
            ('float',52),
            ('money',64),
            ('smallmoney',64),
            ('smalldatetime',52),
            ('datetime',52),
            ('uniqueidentifier',43),
            ('date',69),
            ('datetime2',52),
            ('decimal',42),
            ('nuumeric',42),
            ('char',60),
            ('varchar',60),
            ('nchar',60),
            ('nvarchar',60),
            ('binary',60),
            ('varbinary',60),
            ('xml',60)
    ;
    WITH Sparse_CTE (COLUMN_NAME, SparseComment)
    AS
    (
    SELECT      P.COLUMN_NAME
                ,CASE
                WHEN P.PercentageNulls >= T.Threshold THEN 'Could benefit from sparse columns. '
                ELSE ''
                END AS SparseComment
    FROM        #ProfileData P
                INNER JOIN #SparseThresholds T
                ON P.DataType = T.DataType
    )
    UPDATE      PT
    SET         PT.DataTypeComments =
                CASE WHEN PT.DataTypeComments IS NULL THEN CTE.SparseComment
                ELSE ISNULL(PT.DataTypeComments,'') + CTE.SparseComment + '. '
                END
    FROM        #ProfileData PT
                INNER JOIN Sparse_CTE CTE
                ON PT.COLUMN_NAME = CTE.COLUMN_NAME
    -----------------------------------------------------------------------
    -- Optional advanced analysis
    -----------------------------------------------------------------------
    IF @AdvancedAnalysis = 1
    BEGIN
    -----------------------------------------------------------------------
    -- Data at data boundaries
    -----------------------------------------------------------------------
        IF OBJECT_ID('tempdb..#LimitTest') IS NOT NULL
        DROP TABLE tempdb..#LimitTest;

        CREATE TABLE #LimitTest (COLUMN_NAME VARCHAR(128), NoAtLimit BIGINT);

        DECLARE @advancedtestSQL VARCHAR(MAX) = 'INSERT INTO #LimitTest (COLUMN_NAME, NoAtLimit)' + CHAR(13)
        SELECT      @advancedtestSQL = @advancedtestSQL + 'SELECT '''+ COLUMN_NAME + ''', COUNT('+ COLUMN_NAME + ') FROM ' + @TABLE_SCHEMA + '.' + @TABLE_NAME +
        CASE
            WHEN DataType IN ('numeric', 'int', 'bigint', 'tinyint', 'smallint', 'decimal', 'money', 'smallmoney', 'float','real') THEN ' WHERE '+ COLUMN_NAME + ' = ' + CAST(ISNULL(MaxDataLength,0) AS VARCHAR(40)) + ' OR '+ COLUMN_NAME + ' = ' + CAST(ISNULL(MinDataLength,0) AS VARCHAR(40)) + CHAR(13) + ' UNION' + CHAR(13)
            ELSE ' WHERE LEN('+ COLUMN_NAME + ') = ' + CAST(ISNULL(MaxDataLength,0) AS VARCHAR(40)) + ' OR LEN('+ COLUMN_NAME + ') = ' + CAST(ISNULL(MinDataLength,0) AS VARCHAR(40)) + CHAR(13) + ' UNION' + CHAR(13)
        END
        FROM        #ProfileData
        WHERE       DataType IN ('numeric', 'int', 'bigint', 'tinyint', 'smallint', 'decimal', 'money', 'smallmoney', 'float','real','varchar', 'nvarchar', 'char', 'nchar', 'binary')

        SET @advancedtestSQL = LEFT(@advancedtestSQL,LEN(@advancedtestSQL) -6)
        EXEC (@advancedtestSQL)

        UPDATE      M
        SET         M.NoAtLimit = T.NoAtLimit
                    ,M.DataTypeComments =
                                            CASE
                                            WHEN CAST(T.NoAtLimit AS NUMERIC(36,2)) / CAST(@ROWCOUNT AS NUMERIC(36,2)) >= @BoundaryPercent THEN ISNULL(M.DataTypeComments,'') + 'Large numbers of data elements at the max/minvalues. '
                                            ELSE M.DataTypeComments
                                            END
        FROM        #ProfileData M
                    INNER JOIN #LimitTest T
                    ON M.COLUMN_NAME = T.COLUMN_NAME

    -----------------------------------------------------------------------
    -- Domain analysis
    -----------------------------------------------------------------------
        IF OBJECT_ID('tempdb..#DomainAnalysis') IS NOT NULL
        DROP TABLE tempdb..#DomainAnalysis;

        CREATE TABLE #DomainAnalysis
        (
        DomainName NVARCHAR(128)
        ,DomainElement NVARCHAR(4000)
        ,DomainCounter BIGINT
        ,DomainPercent NUMERIC(7,4)
        );

        DECLARE @DOMAINSQL VARCHAR(MAX) = 'INSERT INTO #DomainAnalysis (DomainName, DomainElement, DomainCounter) '
        DECLARE SQLDOMAIN_CUR CURSOR LOCAL FAST_FORWARD FOR
        SELECT COLUMN_NAME, DataType FROM #ProfileData WHERE NoDistinct < @DistinctValuesMinimum
        OPEN SQLDOMAIN_CUR
        FETCH NEXT FROM SQLDOMAIN_CUR INTO @COLUMN_NAME, @DATA_TYPE

        WHILE @@FETCH_STATUS = 0
        BEGIN
        SET @DOMAINSQL = @DOMAINSQL + 'SELECT ''' + @COLUMN_NAME + ''' AS DomainName, CAST( '+ @COLUMN_NAME + ' AS VARCHAR(4000)) AS DomainElement, COUNT(ISNULL(CAST(' + @COLUMN_NAME + ' AS NVARCHAR(MAX)),'''')) AS DomainCounter FROM ' + @TABLE_SCHEMA + '.' + @TABLE_NAME + ' GROUP BY ' + @COLUMN_NAME + ''
        + ' UNION '
        FETCH NEXT FROM SQLDOMAIN_CUR INTO @COLUMN_NAME, @DATA_TYPE
        END

        CLOSE SQLDOMAIN_CUR
        DEALLOCATE SQLDOMAIN_CUR

        SET @DOMAINSQL = LEFT(@DOMAINSQL, LEN(@DOMAINSQL) -5) + ' ORDER BY DomainName ASC, DomainCounter DESC '
        EXEC  (@DOMAINSQL)

    -- Now calculate percentages (this appraoch is faster than doing it when performing the domain analysis)
        ;
        WITH DomainCounter_CTE (DomainName, DomainCounterTotal)
        AS
        (
        SELECT      DomainName, SUM(ISNULL(DomainCounter,0)) AS DomainCounterTotal
        FROM        #DomainAnalysis
        GROUP BY    DomainName
        )
        UPDATE      D
        SET         D.DomainPercent = (CAST(D.DomainCounter AS NUMERIC(36,4)) / CAST(CTE.DomainCounterTotal AS NUMERIC(36,4))) * 100
        FROM        #DomainAnalysis D
                    INNER JOIN DomainCounter_CTE CTE
                    ON D.DomainName = CTE.DomainName
        WHERE       D.DomainCounter <> 0

    END  -- Advanced analysis

    -----------------------------------------------------------------------
    -- Output results from the profile and domain data tables
    -----------------------------------------------------------------------
    select * from  #ProfileData
    IF @AdvancedAnalysis = 1
    BEGIN
    select * from  #DomainAnalysis
    END
END TRY

BEGIN CATCH
SELECT
        ERROR_NUMBER() AS ErrorNumber
        ,ERROR_SEVERITY() AS ErrorSeverity
        ,ERROR_STATE() AS ErrorState
        ,ERROR_PROCEDURE() AS ErrorProcedure
        ,ERROR_LINE() AS ErrorLine
        ,ERROR_MESSAGE() AS ErrorMessage;
END CATCH

This results in the following table:
